ResiTHERM® 37

Distance mounting system for hollow bricks - strong, fast and with thermal separation!

Product image of distance mounting system ResiTHERM 37/120 M12

Product image of cartige injection mortar ResiFIX VY 300 SF, Vinylester with two mixing nozzles

Product overview

ResiTHERM® 37 is the perfect ETA-approved solution for distance installations in hollow bricks. It is a heavy-duty system for fastening of awnings, canopies, French balconies, railings, satellite dishes etc. in ETICS. Almost no thermal bridge due to a robust glass fibre-reinforced nylon body.

The 80 mm deep internal thread allows a perfect thermal separation as well as a big insertion depth of the threaded stud. Threaded stud, nut and washer out of stainless steel A4 for optimal corrosion resistance. Special membrane for an even distribution of the injection resin (tailored to ResiFIX VY) for high application safety. Massive anchor body made out of glass fibre-reinforced and ageing resistant high-quality nylon ensures long-term security. Comfortable injection of the resin ResiFIX from outside. The mixing nozzle sticks in the injection hole, this makes it easier to adjust the protrusion to the plaster.

Large application range due to the metric thread M12. M12 is the most common thread size for awnings, canopies, French balconies, etc. Product is ready to use: Available in three standard lengths ResiTHERM® 37/120, 37/160, 37/200 mm for the most common insulation thicknesses. Suitable for insulated hollow bricks and insulated aerated concrete.

Made in Germany.

For heavy-duty installations in non-insulated hollow brick walls, we recommend ResiTHERM® 37S.

Find the correct product for you with our ResiTHERM® overview - Discover the full distance mounting system range.
