Distance washer AS, DIN 9021

Accessory for ResiTHERM® 37

Product overview

Use the AS distance washer- if required - for relining between wall and mounting part. Matching the ResiTHERM® 37 distance mounting system, the M12 threaded rod made of A4 stainless steel can be inserted through the distance washer and then screwed into the internal thread of the already mounted ResiTHERM® 37 heavy duty sleeve. ResiTHERM® 37 is available for insulated facades with an insulation thickness of up to 200 mm and ResiTHERM® S for non-insulated facades.

The distance washer AS is made of polyamide and packed by 50 units. It has an outer diameter of 37 mm, inner diameter of 13 mm and height of 3 mm.

Note that if you have already purchased a he ResiTHERM® 37 starter set, 50 units of the distance washer AS are already included in the set.

Download documents

List of references

Reference

129021AS

Diameter [mm]

Inner diameter [mm]

Height [mm]

Material

Polyamide

Packaging units

Packaging type.

Box

1 / 1 references are shown

Applications

Awnings
Canopies
Satellite dishes
Sun protection sails
French balconies
Railings
Building constructions
Window bars

Further specifications

Key features:

Accessory for quick installation of the ResiTHERM®

Base materials:

Hollow brick
Aerated concrete
Hollow sand-lime block
