ResiTHERM® 37 starter set

Distance mounting system for hollow bricks - strong, fast and with thermal separation!

Product image of starter set distance mounting system ResiTHERM in universal box

Product image of cartige injection mortar ResiFIX VY 300 SF, Vinylester with two mixing nozzles

Product image of StickFX professional all-purpose adhesive XP

Product image of core bit for perforated brick BST

Product image of adapter shank AD 200 for core bit BST

Product overview

ResiTHERM® 37 starter set is the perfect ETA-approved solution for distance installations in hollow bricks. It is a heavy-duty system for fastening of awnings, canopies, French balconies, railings, satellite dishes etc. in ETICS. Almost no thermal bridge due to a robust glass fibre-reinforced nylon body.

The 80 mm deep internal thread allows a perfect thermal separation as well as a big insertion depth of the threaded stud. Threaded stud, nut and washer out of stainless steel A4 for optimal corrosion resistance. Special membrane for an even distribution of the injection resin (tailored to ResiFIX VY) for high application safety. Massive anchor body made out of glass fibre-reinforced and ageing resistant high-quality nylon ensures long-term security. Comfortable injection of the resin ResiFIX from outside. The mixing nozzle sticks in the injection hole, this makes it easier to adjust the protrusion to the plaster. Large application range, the metric thread M12- the most common thread size for awnings, canopies, French balconies, etc. The product is ready to use. Made in Germany.

The starter set includes:

- 4x ResiTHERM® 37 M12 of your choice (length 37/120, 37/160, 37/200 M12)

- 4x threaded stud M12x70 mm, stainless steel A4

- 4x washer M12 DIN 125, stainless steel A4

- 4x Hexagon nut M12 DIN 934, stainless steel A4,

- 2x Injection system ResiFIX VY 300 SF incl 4x mixing nozzle MD

- 1x Drilling aid for core bit

- 1x Core bit Ø39 x 220 mm

- 1x Adapter shank hexagon M16, 100 mm for core bit

-1x Adapter shank hexagon M16, 200 mm for core bit

- 1x Stick FX XP white, MS Polymer

- 1x Chaulkinggun APVM suitable for ResiFIX cartridge

- 50x Distance washer DIN 9021 for M12 (13x37x3mm)

- 1 pair of work gloves

Download documents

List of references

Filters

Reference

Plug length [mm]

Suited insulation thickness [mm]

Sort by

Column

Sort direction

Reference

SYS120RTH4

SYS160RTH4

SYS200RTH4

Diameter [mm]

Length [mm]

120

160

200

Plug length [mm]

245

285

325

Suited insulation thickness [mm]

80-120

120-160

160-200

Drill hole diameter [mm]

39-40

Drill hole depth [mm]

130

Anchorage depth [mm]

125

Packaging units

Packaging type.

Plastic box

3 / 3 references are shown

Applications

Awnings
Canopies
Satellite dishes
French balconies
Guard rails
Building constructions
Sun protection sails
Window bars

Further specifications

Key features:

The perfect solution for distance installations in hollow bricks
Excellent thermal separation, almost no thermal bridge
Specialized system for fastening of awnings, canopies, French balconies, railings, satellite dishes etc.
Easy and fast installation saves time and money
Product is ready to use: available in three standard lengths
Outstanding high values in hollow bricks
Suitable for large insulation thickness up to 200 mm
For non-insulated hollow brick walls: ResiTHERM® S
