ResiTHERM® 16

Distance mounting system for insulated façades – ETA-approved and driving rain tight for heavy loads

Product image of distance mounting system ResiTHERM® 16

Product image of distance mounting system ResiTHERM® 16 thermal separation module

Product image of distance mounting system ResiTHERM® 16 embossing in the thermal separation module

Product overview

ResiTHERM® 16 makes the difference! The innovative product is fast, driving rain tight, thermally separated, corrosion-resistant, ETA-approved, and Made in Germany. The perfect solution for mounting heavy loads to insulated facades without thermal bridges!

One product for all insulation types and thicknesses, e.g. bridging insulation thicknesses from 60-300 mm when anchoring in insulated façades made of concrete, or from 60-280 mm in aerated concrete and solid brick, and 60-250 mm when the insulated wall consists of perforated bricks, thus allowing for high application flexibility.

It also works in other base materials and for a wide range of applications such as awnings, canopies, French balconies, satellite dishes, air-conditioning units and much more.

The black thermal separation module eliminates heat bridges efficiently and protects against mould and heat loss. Its pre-assembled, weather-resistant EPDM sealing ensures safe sealing against driving rain up to wind force 11(violent storm) and up to 3 mm displacement, tested for watertightness based on DIN EN 1027.

Discover the time and cost savings due to simple and quick installation while ensuring the highest quality:

No risk of corrosion due to high steel quality 8.8, attachment parts made of stainless steel A4 and glass-fibre reinforced nylon, which is characterised by ageing, weather, and UV-resistance.

The possibility of subsequent adjustment of the screw-in depth of the M12 threaded stud as well as the M16 threaded rod allows adjustment to the individual installation situation.

ResiTHERM® 16 is available in two versions: zinc-plated or A4.

While the external attachment parts M12 are always made of A4 stainless steel, the variants differ for the M16 threaded rod in the wall. For one variant this threaded rod is galvanised, for the other, it consists of A4 stainless steel.

Each variant is available in 2 or 20 pieces.

Find the correct product for you with our ResiTHERM® overview - Discover the full distance mounting system range.

Request samples

Download documents

View videos

List of references

Filters

Reference

Material

Packaging units

Sort by

Column

Sort direction

Reference

9250RTH162

9250RTH1620

9X250RTH162

9X250RTH1620

Plug length [mm]

385

Suited insulation thickness [mm]

60-300

Material

Steel

Stainless steel A4

Drill hole depth [mm]

90/110/140+e

Drill hole diameter [mm]

18/20

Eff. Anchorage depth [mm]

80/100/130

Thread

M16

Packaging units

Packaging type.

Box

4 / 4 references are shown

Applications

Canopies
Awnings
Air conditioner
Satellite dishes
Guard rails
Building constructions
Sun protection sails
Window bars
Rainwater downpipes

Further specifications

Key features:

High application flexibility: One set for all insulation types and thicknesses from 60-300 mm in concrete and 60- 250 mm in perforated bricks
Time and cost savings due to simple and quick installation
Reliable, durable, ETA-tested fixing
Thermal separation module eliminates heat bridges efficiently and protects against mould and heat loss
Pre-assembled, weather resistant EPDM sealing ensures safe sealing against driving rain up to wind force 11 (violent storm) and up to 3 mm displacement, tested watertightness based on DIN EN 1027.
It is possible to adjust the screw-in depth of the M12 threaded stud and the M16 threaded rod whilst keeping within the ETA.
Stainless steel A4 for outdoor installation
Made of robust glass-fibre reinforced nylon
Complies with the Regulation of Thermal Installations of Buildings 1027/2007 (RITE)
