Cable tie mount TBB for FORCE ONE

Specially designed for FORCE ONE and FOX nailers to install lightweight pipes and cables using cable ties

Product image of cable tie fastener TBB black

Product image of cable tie fastener TBB grey

Product overview

The TBB cable tie mount is the ideal quick and comfortable solution for fixing lightweight pipes using cable ties. Due to its design, the mount can be easily clamped to the nose of the nailer where it achieves its optimum time-saving performance, especially when installed with the FORCE ONE gas nailer. It can be used flexibly, as it is suitable for various pipe diameters.

After installation, the 4 side openings allow easy insertion of cable ties and the fixing of pipes in all directions. The rounded shape enables the self-centring of the pipe or clamp.

Supports cable ties up to 10 mm in width. Available in two colours: grey and black.

This model is compatible with: FORCE ONE and FOX nailers.

Halogen-free, RoHS compliant, Made in Germany.

Download documents

View videos

List of references

Filters

Colour

Reference

9TBB

9GRTBB

Diameter [mm]

24.5

Height [mm]

Material

Nylon

Colour

Black

Grey

Packaging units

100

Packaging type.

Box

2 / 2 references are shown

Applications

Cable installation
Steel pipes
PVC pipes
Corrugated pipes
Ventilation pipes
Insulated pipes

Further specifications

Key features:

Versatile
Easy to install, opening on four sides
Curved geometry allows a better settlement of the tubes
Designed to work in any position
Compatible with gas nailers FORCE ONE, Würth Diga C3, Spit 700/800, Rawlplug

Base materials:

Steel
Concrete
Hollow concrete block
Solid stone
Wood

How to install

Step 1

Step 2

Step 3

Step 4

Watch the video
