Set screw beam clamp PMV

Suspension of threaded rods from beam flanges
PMV Beam Clamp for Threaded Rod Mounting
Packaging photo of box containing 20 pieces of PMV M10, zinc plated, side view
Packaging photo of the back side of the CELO box 9N-6
Packaging photo of box containing 20 pieces of PMV M10, zinc plated, front view with label
Product overview

The setscrew PMV is a certified heavy load flange beam clamp to suspend threaded rods from beams with flange thicknesses up to 26 mm. You save time with the PMV beam clamp, as clamp, hexagon head screw and lock nut are pre-assembled and can be used directly. The PMV setscrew is quickly installed without drilling or welding simply by tightening the screw. Plus, for further time-saving, hexagon head screw and lock nut can be tightened with the same key.

Show more
Download documents
View videos
List of references
Filters
Screw diameter [mm]
8
10
12
Close
Min. Flange Length [mm]
21
29
32
Close
Width [mm]
19
21
23.5
Close
Height [mm]
35
42
54
Close
Internal thread
M8
M10
M12
Close
Reference
98PMV
910PMV
912PMV
Length [mm]
38
50
58
Screw diameter [mm]
8
10
12
Flange thickness [mm]
Min. Flange Length [mm]
21
29
32
Width [mm]
19
21
23.5
Height [mm]
35
42
54
Internal thread
M8
M10
M12
Packaging units
20
20
10
Packaging type.
Box
Box
Box
A
t
3 / 3 references
Applications
  • Suspended structure
  • Electrical installations
  • Industrial HVAC
  • Threaded rods
  • Sprinkler systems
  • Heating pipes
  • Ventilation lines
  • Air conditioning pipes
  • Steel constructions
Further specifications

Key features:

  • Quick assembly without drilling or welding simply by tightening the screw
  • Ready-to-use as all parts are pre-assembled for quicker installation
Base materials
Suitable materials
Steel beam/purlin
Steel beam/purlin
Other related products
How to install
Mounting a PMV Beam Clamp
Hand-tightening the Screw on the PMV Beam Clamp
Final Tightening of the Screw on the PMV Beam Clamp with a Wrench
Hand-tightening the Nut on the PMV Beam Clamp
Tightening the Nut on the PMV Beam Clamp with a Wrench by 45°
Inserting a Threaded Rod into the PMV Beam Clamp
