Quick EPDM rubber lined pipe clamp M8+M10 RIF

Quick installation system EPDM rubber lined clamp M8+M10
Product image of quick clamp RIF
Technical drawing of quick clamp RIF
Mounting image RIF 1
Mounting image RIF 2
Mounting image RIF 3
Product overview

The RIF quick clamp saves you valuable installation time, because only one screw has to be tightened. This quick and easy closing mechanism reduces installation time by 30% compared to standard clamps with two screws. The multifunction screw has a hexagonal combination head (slot and crosshead).

Show more
List of references
Filters
Reference
915RIF
918RIF
922RIF
928RIF
935RIF
940RIF
948RIF
960RIF
Close
Diameter [mm]
15
18
22
28
35
40
48
60
Close
Clamping range [mm]
18
22
28
35
40
48
60
Close
Inner diameter [mm]
12-14
15-19
20-23
25-28
32-35
40-43
48-52
57-62
Close
Length [mm]
45
47
53
59
65
73
80
94
Close
Height [mm]
46
48
54
60
64
72
81
95
Close
Packaging units
25
20
10
Close
Sort by
Column
Reference
Diameter [mm]
Clamping range [mm]
Inner diameter [mm]
Length [mm]
Height [mm]
Width [mm]
Connecting thread
Packaging units
Packaging type.
Close
Sort direction
Ascending
Descending
Close
Reference
915RIF
918RIF
922RIF
928RIF
935RIF
940RIF
948RIF
960RIF
Diameter [mm]
15
18
22
28
35
40
48
60
Clamping range [mm]
18
18
22
28
35
40
48
60
Inner diameter [mm]
12-14
15-19
20-23
25-28
32-35
40-43
48-52
57-62
Length [mm]
45
47
53
59
65
73
80
94
Height [mm]
46
48
54
60
64
72
81
95
Width [mm]
20
20
20
20
20
20
20
20
Connecting thread
M8+M10
M8+M10
M8+M10
M8+M10
M8+M10
M8+M10
M8+M10
M8+M10
Packaging units
25
25
20
25
25
25
20
10
Packaging type.
Box
Box
Box
Box
Box
Box
Box
Box
8 / 8 references are shown
Applications
  • Steel pipes
  • Copper pipes
  • PVC pipes
  • Heating pipes
Further specifications

Key features:

  • The fast fixations system allows the closing with a single hand and frontal assembly
  • Resists temperatures from -50ºC to + 110ºC
  • EPDM rubber according to DIN 4109 standard insulated and soundproof
  • Pull out resistance 80 Kg security factor included
