Chipboard screw VELOX® PZ 4,5x35, full thread, zinc plated

High Performance from tip to head
Chipboard screw VELOX® PZ 4,5x35, full thread, zinc plated
Graphic PZ drive
Graphic SIT screw- flush finishing in metal fittings
Application image of chipboard screw Velox PZ: chipboard construction
Application image of chipboard screw Velox PZ: wooden stairs
EN - Technical drawing of chipboard screw VELOX PZ full thread
A Back to combination list
Reference:
94535VLOX
Coating :
Galvanised
Recess type :
PZ2
Thread th:
Full thread
Material :
Steel
Head type :
Countersunk head
Screw diameter [mm] ds:
4.5
Thread length [mm] Lth:
32.45
Head diameter [mm] dh:
9
Head height [mm] Hk:
2.55
Screw length [mm] Ls:
35
Packaging units:
500
Packaging type.:
Box
GTIN:
8425586435435
Download documents
Reference Description
94535VLOX

The blue zinc plated chipboard screw VELOX® PZ 4,5x35 with full thread guarantees high user safety as confirmed by the ETA-assessment (12/0198) for use in timber construction. The patented tip thread area reduces splitting of wood as well as setting torque, which provides a perfect appearance and increases your productivity (longer battery life). Due to the low-friction sliding coating and the sharp thread the setting torque is further reduced and you save time during the installation.

VELOX® PZ with countersunk head and proven POZI drive is your fast choice for wood, chipboard, laminated and veneered wood as well as for fastening with plastic plugs.

Screw diameters Ø3,5 - Ø5 are perfect for metal fittings because of their internal underhead milling pockets for flush fitting and fewer wood shavings.

Applications
  • Wood furniture
  • Wood doors
  • Wood windows
  • Chairs
  • Wood frames
  • Fittings
Further specifications

Key features:

  • Patented thread reduces splitting as well as ­setting torque, which provides a perfect appearance and a longer battery life
  • Sharp tip allows easy insertion into chipboard
  • Sharp thread allows fast screwing speed
  • Double cone and deeper POZI recess for increased safety and better transmission of the tightening.
  • Especially well-suited for nylon plugs
  • Galvanized; blue passivated
  • European Technical Approval ETA-12/0198 for use in timber constructions
  • ETA-approved product for your safety
Base materials
Suitable materials
Wood
Wood
Chipboards
Chipboards
