Concrete screw BTS PT 5-60/35, Pan head TX25, zinc flake coating
Universal screw for direct and fast fixing
A Back to combination list
Reference:
9ZG560BTSPT
Coating :
Zinc flake coating
Head type :
Pan head
Material :
Steel
Recess type :
TX25
Drill hole diameter [mm] d0:
5
Drill hole depth [mm] h1:
35
Anchorage depth [mm] hnom:
25
Screw diameter [mm] ds:
6.4
Thickness of fixture [mm] tfix:
35
Head diameter [mm] dh:
10
Clearance hole [mm] df:
7.5
Anchor length [mm] La:
60
Packaging units:
100
Packaging type.:
Box
GTIN:
4250438921453
Reference Description
9ZG560BTSPT
The concrete screw BTS5 PT 5-60/35 with pan head (TX 25. Kopf-Ø: 10 mm) is perfectly suited for a direct and fast fastening in different base materials. Due to the small drill hole of only 5 mm and the low setting depth of only 25 mm, a very low screw-in force is required. It is even possible to install it manually without a screwdriver. The small concrete screw even holds loads of up to 80 kg in concrete. The zinc flake coating provides high corrosion protection. The BTS5 is well suited for electrical and sanitary fixings.
Applications
- Electrical installations
- Sanitary fixings
Further specifications
Key features:
- Direct and fast fixing
- Small pre-drill with 5mm drill bit
- Manual installation without battery screwdriver
- Low embedment depth of only 25 mm
- Suitable for fixing the metal clips F and DF
- Tested according to DIN 4102-12 (functional integrity)
- Complies with the Regulation of Thermal Installations of Buildings 1027/2007 (RITE)
Base materials:
- Concrete
- Solid brick
- Solid sand-lime brick
- Hollow brick
- Natural stone
